General
Dimensions
144.2×44.4×33.5 mm (L×W×H)
Weight
190.5 g
Number of Microphones
3
Touchscreen
Size: 2.0 inches
Resolution: 556×314
Brightness: 1000 nits
Supported SD Cards
microSD (up to 1 TB)
Recommended microSD Cards
Recommended models:
Lexar Silver Plus 64GB U3 A2 V30 microSDXC
Lexar Silver Plus 128GB U3 A2 V30 microSDXC
Lexar Silver Plus 256GB U3 A2 V30 microSDXC
Lexar Silver Plus 512GB U3 A2 V30 microSDXC
Lexar Silver Plus 1TB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 1TB U3 A2 V30 microSDXC
Gimbal
Controllable Range
Pan: -235° to 58°
Tilt: -120° to 70°
Roll: -45° to 45°
Mechanical Range
Pan: -240° to 63°
Tilt: -180° to 98°
Roll: -220° to 63°
Max Controllable Speed
180.0°/s
Angular Vibration Range
±0.005°
Camera
Sensor
1-inch CMOS
Lens
Format Equivalent: 20 mm
Aperture: f/2.0
Focus Range: 0.2 m to ∞
ISO Range
Photo: 50-12800
Video: 50-12800
Low-Light Video: 50-25600
Slow Motion: 50-12800
Electronic Shutter Speed
Photo: 1/8000-4 s
Video (Auto): 1/8000 s to the limit of frames per second
Video (M): 1/8000-1/4 s
Max Image Size
16:9, 7680×4320
1:1, 6144×6144
Zoom
Digital Zoom
Photo: 7680×4320, 2×
Video: 1080p, 4×; 3K, 4×; 4K, 4×
UVC & DP: 4K, 4×
Livestream: 1080p, 4×
Low Light/Slow Motion/Timelapse: Not available
Still Photography Modes
Single Shot: Approx. 37 MP
Countdown: Off/0.5/1/2/3/5/10 s
Panorama: 180°, 3×3
Normal Video
4K (16:9): 3840×2160@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
3K (9:16): 1728×3072@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
Slow Motion
4K (16:9): 3840×2160@100/120/200/240fps
1080p: 1920×1080@120/240fps
Hyperlapse
4K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10/∞ hours
Motionlapse
4K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10 hours
Supports setting four positions
Low-Light Video
4K (16:9): 3840×2160@24/25/30fps
1080p: 1920×1080@24/25/30fps
Max Video Bitrate
180 Mbps
Supported File System
exFAT
Photo Format
JPEG/DNG/JPEG+DNG
Video Format
MP4 (HEVC)
Built-in Storage Capacity
The camera has 107 GB of built-in storage. The storage capacity can be expanded by inserting a microSD card.
Audio Output
48 kHz 16-bit; AAC
Battery
Type
Li-ion
Capacity
1545 mAh
Energy
11.95 Wh
Voltage
7.74 V
Operating Temperature
0° to 40° C (32° to 104° F)
Charging Temperature
5° to 45° C (41° to 113° F)
Operating Time
240 mins
Tested at room temperature of 25° C (77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only.
Charging Time
18 mins to 80%; 32 mins to 100%
Tested in a laboratory environment with the DJI 65W Portable Charger (sold separately).
Connection
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Protocol
802.11 a/b/g/n/ac/ax
Wi-Fi Transmitter Power (EIRP)
2.4 GHz:
< 20 dBm (CE/SRRC/MIC)
5.1 GHz:
< 23 dBm (SRRC)
< 20 dBm (CE)
5.8 GHz:
< 23 dBm (SRRC)
< 14 dBm (CE)
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
< 14 dBm
Bluetooth Protocol
BLE 5.4, BR/EDR
